Teltonika TRB140 LTE Router: No WiFi, 4G, SIM, Enthernet port, Micro USB | LTE Router | TRB140 | No Wi-Fi | 10/100/1000 Mbit/s | Ethernet LAN (RJ-45) ports 1 | Mesh Support No | MU-MiMO No | 2G/3G/4G | Antenna type 1 x SMA for LTE | 1 x Virtual network interface via micro USB | 24 month(s)
| Gross depth (mm) | 175 mm |
| Paper/Pasteboard | 123 g |
| Tare weight (kg) | 0.123 kg |
| Volume (m3) | 0.0018375 m³ |
| USB ports quantity | 1 x Virtual network interface via micro USB |
| Producer product name | TRB140 |
| Producer product family | LTE Router |
| Wi-Fi band | No Wi-Fi |
| Software type | RutOS (OpenWrt based Linux OS) |
| Mobile Broadband | 2G/3G/4G |
| Antenna type | 1 x SMA for LTE |
| Processor model | ARM Cortex-A7 1.2 GHz CPU |
| SFP+ ports quantity | 0 |
| Internal memory | 128 MB (50 MB available for userspace) GB |
| Housing material | Aluminum |
| Operating relative humidity (H-H) | 10 % to 90 % non-condensing % |
| Dimensions (WxDxH) | 74,5x64,4xx25 mm |
| Operating temperature (T-T) | -40 °C to 75 °C °C |
| PoE in | Passive PoE over spare pairs. Possibility to power up through LAN port, not compatible with IEEE802.3af, 802.3at and 802.3bt standards |
| Input voltage | 9 – 30 VDC (4 pin industrial socket), reverse polarity protection, surge protection >33 VDC 10us max V |
| Supported protocols | HTTP(S), MQTT, Azure MQTT, Kinesis |
| Firewall security | Pre-configured firewall rules can be enabled via the WebUI, unlimited firewall configuration via CLI; NAT; NAT-T |
| Supported network protocols | TCP, UDP, IPv4, IPv6, ICMP, NTP, DNS, HTTP, HTTPS, SMTP, SSL v3, TLS, PPP, PPPoE, SSH, DHCP, SNMP, MQTT, Wake on LAN (WOL) |
| Net weight master carton | 4.3 kg |
| Tare weight master carton | 0.401 kg |
| Producer | Teltonika |
| Palette Qty | 730 pc(s) |
| Gross weight | 0.43 kg |
| Net weight | 0.307 kg |
| Packing quantity | 10 pc(s) |
| Ethernet LAN data rates | 10/100/1000 Mbit/s |
| Mesh Support | No |
| MU-MiMO | No |
| Gross depth master carton | 375 mm |
| Gross width master carton | 370 mm |
| Gross height master carton | 170 mm |
