DUCO | DucoBox Energy Comfort Plus D550
| Gross height (mm) | 823.00 mm |
| Gross weight | 49.35 kg |
| Net weight | 47.00 kg |
| Producer | DUCO |
| Paper/Pasteboard | 1880 g |
| Plastic (No PET) | 471 g |
| Gross depth (mm) | 610.00 mm |
| Gross width (mm) | 810.00 mm |
| Tare weight (kg) | 2.35 kg |
| Volume (m3) | 0.41 m³ |
| Palette Qty | 2 pc(s) |
| Producer product name | DucoBox Energy Comfort Plus D550 |
| Dimensions (WxHxL) | 760 x 803 x 584 mm |
| Connections | Internal diameter: 180 mm |
| Colour of product | White/Green |
| Weight | 47 kg |
| Mounting | Wall mounting (standard), Floor mounting as an option using a support frame |
| Material | Inside section: EPP, PP, ABS |
| Heat exchanger | v1: PP-v2: PET/Alu |
| Casing | Coated sheet steel |
| Condensate drain | 32 mm |
| Energy Class | A+ |
| Filter | Dynamic airflow filter supply air, Standard, Optional |
| Sensors | Integrated: pressure, temperature, onboard switch sensor; External: CO2 (via optional Room sensor), Humidity (via optional Room sensor or measurement in ETA duct), external Switch Sensor (voltage-free input) (optional) |
| Power supply | 230 V, 50 Hz via 3-core power cable with earthed plug |
| Motor type | DC |
| IP class | IP40 |
| Efficiency | 84.7 % |
| Flow rate | 550 m³/h |
| Pressure (Pa) | 150 Pa |
| Cable length | 2 m |
